UNLOCK METHODS
BASIC FUNCTION
| Pin Number | 1 |
|---|---|
| RFID Card (external) | 200 |
| RFID Card (internal) | - |
| Fingerprint (external) | 100 |
| Fingerprint (internal) | - |
| Guest Pin Number | 1 |
| Remote Control | 10 |
| Face ID | - |
| Emergency Key (mechanical) | ✓ |
| Home Network | 10 |
| App(BLE/WiFi Bridge) | - |
| Smart Card Auto Recognition / Manual Recognition | ✓ |
|---|---|
| Deadbolt Auto Lock / Manual lock | ✓ |
| Sound Setting (UP/DOWN) | ✓ |
| Door Opening Alarm ON/OFF | ✓ |
| Voice Mode/Buzzer Mode Setting | ✓ |
| Internal Forced Lock ON/OFF | ✓ |
| External Forced Lock ON/OFF | - |
| Alarm Notification ON/OFF | - |
| Dual Authentication ON/OFF | ✓ |
| IR SENSOR ON/OFF | - |
| FeliCa Auto Detection ON/OFF | - |
| Etiquette Mode | ✓ |
OTHER FUNCTION
SPECIFICATIONS
| Low Battery Warning | ✓ |
|---|---|
| 1 Minute Lock Warning | ✓ |
| Deadbolt Operation Error Warning | ✓ |
| Intrusion Alarm | ✓ |
| High Temperatur Alarm | ✓ |
| Internal Forced is being enabled | ✓ |
| External Forced is being enabled | - |
| Random Number Feature | ✓ |
| Checking The Duration Of Use | ✓ |
| Automatic Lock/Re-lock | ✓ |
| Locking from Outside/Inside | ✓ |
| Emergency Power Terminal | ✓ |
| Outer body (W x H x D mm) | 85 x 376 x 75 |
|---|---|
| Inner body (W x H x D mm) | 85 x 376 x 74 |
| Material | Zn, Al, ABS |
| Applicable Door Thickness(mm) | 40 ~ 50mm |
| Backset(mm) | 70mm |
| Operation Humidity | 20% ~ 80% RH |
| Operation Temperature | 0℃ ~ 40℃ |
| Fire Detection Temperature | 60℃ ± 10℃ |
| Power Supply | DC 6V (LR6 1.5V AA, 8 EA) |
| Emergency Power | DC 9V (6LR61 / 6F22) |
| Battery life (10 times/1 day) | 10 months |
